Stainless Steel 316L Round Screen Filter Perforated Metal Mesh
Description
The perforated metal mesh is stamped from the original steel plate.
Beautiful appearance, widely used in the protection of speakers,
bridges, pedals and various mechanical equipment.
Steel plate materials mainly include steel plate, cold rolled
plate, hot rolled plate, galvanized steel plate, alloy steel plate,
etc.
It is mainly used in high-end residence, villa, private swimming
pool, courtyard lawn, stadium, resort and other fields.
We have advanced numerical control equipment, and the products can
be customized as customers's demand.
Perforated metal mesh is a metal sheet product that has been
punched with a wide variety of hole sizes and patterns, such as
round hole, square hole or slotted hole, etc.
It's widely used in interior and exterior design
Perforated Sheet is also known as perforated metal, perforated
plate, or perforated screen.
Features: the mesh surface is flat, smooth, beautiful, firm and
durable, and has a wide range of applications.
Specification: the thickness of coiled plate is 0.2mm - 1mm, the
length is 1m-20m, and the hole diameter is 0.8mm - 20mm; Plate
thickness 0.3mm - 30mm, min
Specification List| Plate material | Thickness (mm ) | Hole (mm) | Pitch (mm) | Sheet Width(m) | Sheet Length(m) | Porosity (%) | Plate Weight (kg/m2) |
| Steel sheet | 0.5mm | 1mm | 1 | 1 | 2 | 19.6 | 3.14 |
| 0.55mm | 1.1mm | 2.2 | 1 | 2 | 22.67 | 3.411 |
| 0.55mm | 1.5mm | 2.8 | 1 | 2 | 26.03 | 3.268 |
| 0.8mm | 1.5mm | 1.5 | 1 | 2 | 19.6 | 5 |
| 0.8mm | 2mm | 3.4 | 1 | 2 | 30.78 | 4.465 |
| 1.5mm | 2mm | 2 | 1 | 2 | 19.6 | 9.4 |
| 1.5mm | 5mm | 8.0 | 1 | 2 | 35.39 | 7.843 |
| 3mm | 5mm | 16 | 1 | 2 | 19.6 | 18.8 |
| Stainless steel | 0.5mm | 1mm | 1 | 1 | 2 | 19.6 | 3.14 |
| 0.8mm | 1.5mm | 1.5 | 1 | 2 | 19.6 | 5 |
| 1mm | 2mm | 2 | 1 | 2 | 19.6 | 6.28 |
| 2mm | 5mm | 16 | 1 | 2 | 19.6 | 6.28 |
| Aluminum sheet | 0.5mm | 1mm | 1 | 1 | 2 | 19.6 | 1.08 |
| 0.8mm | 3mm | 3 | 1 | 2 | 19.6 | 1.72 |
| 1.6mm | 2mm | 2 | 1 | 2 | 19.6 | 3.24 |
| 3mm | 4mm | 16 | 1 | 2 | 19.6 | 4.23
|
Product Show
Variety Patterns can be customized
Factors for quotation
1. plate raw material
2. plate thickness
3. hole shape & dimension
4. round hole arrangement
5. open area
6. margin
7. plate dimension(width x length x thickness)
