Roll Light Welded Wire Mesh Galvanized Finish Used For Aviaries
Product Introduction of Roll Light Welded Wire Mesh
| Item Number | BD-WWM | Trade Name | Baodi |
| Product Type | Welded mesh, construction wire mesh |
| Material | Low carbon steel wire, stainless steel wire |
| Surface Treatment | Galvanized or PVC coated |
| Wire Gauge | #14 - #29 | Mesh Opening | 1/4” – 4” |
| Roll Height | 2' / 3' / 3.28' / 4' / 5' / 6' | Roll Length | Maximum 100' |
| Packing | Plastic film or water-proof paper |
- Welded wire mesh typically has larger openings than woven wire
mesh.
- With the wire strands welded at each intersection, welded mesh is
more capable of maintaining its shape when stressed.
- The Welded Wire Mesh is a metal wire screen, which is made up of
low carbon iron wire or stainless steel wire.
- It is available in various sizes and shapes.It's available in
various roll height: 2' / 3' / 3.28' / 4' / 5' / 6'.
- It could be packed in plastic film or waterproof paper.
NOTE: The welded wire mesh could be custom made by our factory.
Different Types:
1. Electro galvanized welded wire mesh
2. Hot dipped galvanized welded wire mesh
3. PVC coated welded wire mesh
4. Stainless steel welded wire mesh
Specification List
| Welded Wire Mesh |
| Wire Diameter<BWG> | Mesh Opening in inch | Mesh Opening in mm |
| 22,23,24 | 1/4" x 1/4" | 6.4mm x 6.4mm |
| 19,20,21,22 | 3/8" x 3/8" | 10.6mm x 10.6mm |
| 16,17,18,19,20,21,22,23 | 1/2" x 1/2" | 12.7mm x 12.7mm |
| 18,19,20,21, | 5/8" x 5/8" | 16mm x 16mm |
| 16,17,18,19,20,21 | 3/4" x 3/4" | 19.1mm x 19.1mm |
| 16,17,18,19,20,21 | 1" x 1/2" | 25.4mm x 12.7mm |
| 14,15,16,17,18,19 | 1-1/2" x 1-1/2" | 38mm x 38mm |
| 14,15,16 | 1" x 2" | 25.4mm x 50.8mm |
| 12,13,14,15,16 | 2" x 2" | 50.8mm x 50.8mm |
Technical Note:
♦ Standard roll length: 30m;width: 0.5m to 1.8m
♦ Special sizes available at request
♦ Packing: in waterproof paper in rolls. Custom packing available
at request.
| Galvanized Fencing Mesh |
| Wire Diameter | Mesh Opening in inch | Mesh Opening in mm |
| 2.0mm,2.5mm,1.65mm | 2" x 3" | 50mm x 75mm |
| 2.67mm,2.41mm,2.11mm,1.83mm,1.65mm | 3" x 3" | 75mm x 756mm |
| 2.11mm,2.5mm | 2" x 4" | 50mm x 100mm |
| 2.0mm,2.5mm | 4" x 4" | 100mm x 100mm |
| PVC Coated Welded Mesh |
| Wire Diameter<BWG> | Opening in inch | Opening in mm |
| 16,17,18,19,20,21 | 1/2" x 1/2" | 12.7mm x 12.7mm |
| 16,17,18,19,20,21 | 3/4" x 3/4" | 19mm x 19mm |
| 15,16,17,18,19,20 | 1" x 1" | 25.4mm x 25.4mm |
Characteristic of Roll Light Welded Wire Mesh
♦ Solid structure
♦ Wires resist movement
♦ Easy handling
♦ Extensive use
♦ High strength
♦ Square pattern
♦ Uniform mesh and smooth surface
♦ Savings in time, labour and money
Application
Welded wire mesh is widely used for:
| pet cages |
| puppy runs |
| rabbit runs |
| aviaries |
| making trays baskets |
| seeding guards |
| squirrel protection |
